156 HyPrecision 50S/60S/75S Operator Manual 808690
6 – Parts lists
Parts lists
Complete list of preventive maintenance kits, parts, tools, and materials
Kits
12084 HyPrecision standard tool kit 15568 HyPrecision S- and D-series poppet repair kit
12981 Bleed-down valve II repair kit 15569 HyPrecision S-series standard spares kit
15563 HyPrecision premium high-pressure seal repair kit
Parts
11518 Indicator pin 11608 Plunger bearing
11520 Low-pressure poppet basket 11609 Seal housing
11521 Spacer tube 12943 High-performance bleed-down valve body
11522 High-pressure cylinder 11960 Suction strainer, 2-1/2 inch
11523 Check valve assembly 12438 Suction strainer, 1-1/2 inch
11530 Output adapter 14629 Filler-breather cap
Tools
All wrenches and sockets are SAE
13897 TDS meter Flat-blade screwdriver
Full set of standard open-ended wrenches Rubber mallet
Full set of standard crowfoot wrenches or sockets Two 8-32 × 2-inch (or longer) socket-head cap screws
1/8-inch hex wrench Infrared or other type of external-reading thermometer
5/32-inch hex wrench or hex-bit socket Air pressure gauge (Schrader valve)
Adjustable wrench Compressed air source
Torque wrench Dental pick or similar tool (recommended)
Strap wrench or adjustable pliers
Materials
11210-30 30-micron lapping paper Clean, lint-free towels
11111 Blue Goop high-pressure antiseize lubricant Nonstick scouring pad
11448 AccuGoop food-grade high-pressure antiseize lubricant Emery cloth (not coarser than 120 grit)
11447 High-vacuum grease Masking tape
13186 Antiseize bolt lubricant (white lithium grease) Container for a water sample
13969 Petroleum-based O-ring lubricant Container for used hydraulic fluid
Isopropyl alcohol Hose or pipe for draining hydraulic fluid
Clean, deionized water or filtered water Clean funnel (recommended)
Antiwear (AW) mineral oil or synthetic hydraulic
fluid, ISO viscosity grade (VG) 32 or 46
Bucket or pail (recommended)
