192 HyPrecision 50S/60S/75S Operator Manual 808690
9 – Installation
Installation
Remote pump on
If the pump is off, this input performs a sequential startup of the pump.
If the pump is running in cooling mode, this input causes the intensifier to start stroking.
Remote pump off
This input turns off the intensifier, the boost pump, the primary motor, the low-pressure water, and the cooling fan.
Remote low pressure
This input permits the operator to put the pump in pierce-pressure mode.
Remote cooling on
This input turns on the fan motor and the cooling water or the cooling fan logic, and turns off the intensifier.
Wire number Type of contact
Operation
6028 Input, momentary, normally open
Status
6028 Input, momentary, normally open
Emergency stop
5024A, 5024B
A jumper is installed between
these terminals at the factory.
Normally closed
Wire number Type of contact
Operation
6029 Input, momentary, normally closed
Status
6029 Input, momentary, normally closed
Wire number Type of contact
Emergency stop
6031
Input, momentary or maintained,
normally open
Wire number Type of contact
Emergency stop
6030
Input, momentary or maintained,
normally open
