Hypertherm Powermax105 User Manual

Machine Torch SeTup
6-40 Powermax105 Operator Manual
105 A Unshielded cutting (Stainless Steel)
Air flow rate – slpm/scfh
Hot 217 / 460
Cold 250 / 530
Metric
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
mm mm mm % seconds (mm/min) Volts (mm/min) Volts
6
4.6
9.2 200
0.5
4970 145 6120 142
8 3420 147 4210 144
10 2090 149 2570 146
12 1410 151 1740 149
16 0.75 880 153 1080 151
20 1.0 660 156 800 155
25
Edge Start
420 159 500 159
30 330 162 370 161
32 300 163 320 162
English
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
inches inches inches % seconds ipm Volts ipm Volts
1/4
0.18
0.36 200
0.5
185 145 228 142
3/8 88 149 108 145
1/2 52 151 64 149
5/8 0.75 35 153 43 151
3/4 1.0 28 155 34 154
7/8
Edge Start
22 157 26 157
1 16 159 19 159
1-1/8 14 161 16 161
