Hypertherm powermax1250 Service Manual

MAINTENANCE
powermax1250 Service Manual 3-33
4
T80M machine torch: connector pinout diagrams and assembly
Blue rubber seal
White wires (plunger)
Red dot
Pin 1
Pin 10 not used
Orange wire (cap sense)
Pin 12 blue wire (cap sense)
Pin 3
Red wires (nozzle)
Screws (3)
Mounting
sleeve
Torch
body
O-ring
Positioning
sleeve
Strain
relief
lock
Strain
relief
J18
1
2
3
4
5
6
7
8
9
10
11
12
WHITE
WHITE
RED
ORANGE
NOZZLE
ELECTRODE
CAP
BLUE
