3-12
MAINTENANCE
powermax600 Service Manual
Figure 3-4 Resistance Check #2 - Power Board to Chassis
Resistance Check #2 - Figure 3-4
• Check resistance from power board connection to chassis.
> 10MΩ
> 10MΩ
230V and 400V
208-240V and 480V
PMX600.20
10-99
