MAINTENANCE
3-13
powermax600 Service Manual
230V and 400V
208-240V and 480V
PMX600.21
+
+
Resistance Check #3 - Figure 3-5
• Check resistance across output diode bridge.
Figure 3-5 Resistance Check #3 - Output Diode Bridge
6 to 9 KΩ
4 to 7 KΩ
