Troubleshoot Common Problems
6
140 810470 Operator Manual Powermax65/85/105 SYNC
0-50-0
Yellow
Yellow
The cartridge is off, or the
torch was in the yellow
lock (X) position during a
restart.
This fault code stops the system from operating.
Do the following.
• This fault code shows when you do a restart
while the torch-lock switch is in the yellow
lock (X) position. Move the torch-lock
switch to the green “ready to fire” ( )
position to continue. Refer to fault code
0-50-1, below.
• This fault code also shows when a cartridge
is not installed correctly. Remove the
Hypertherm cartridge, and install it correctly.
• Machine torch: This fault code shows when
you remove the cartridge without first
setting the power switch to OFF (O) or
moving the torch-lock switch to the yellow
lock (X) position. Lock and unlock the torch,
or do a quick restart.
• Mini machine torch: This fault code can
show if you change the cartridge while the
power switch on the plasma power supply
is set to ON (I). Do a quick restart.
• In some conditions, this fault code can
show when the torch is not connected.
Make sure that the torch lead is correctly
connected to the FastConnect receptacle
on the front of the plasma power supply. Do
a quick restart.
• If the Hypertherm cartridge is in good
condition and is installed correctly, the torch
has possible damage. Speak to your
distributor or authorized repair facility.
0-50-1
Yellow
Yellow
The torch-lock switch is set to
the yellow lock (X) position.
This fault code stops the system from operating.
Do the following. A restart is not necessary.
• Hand torch: Move the torch-lock switch to
the green “ready to fire” ( ) position. Fire
the torch 1 time to get the warning puffs of
air. Fire the torch again to get a plasma arc.
Refer to page 70.
• Machine torch: Move the torch-lock switch
to the green “ready to fire” ( ) position.
Fire the torch to get a plasma arc.
• Mini machine torch: This fault code is not
applicable to the mini machine torch.
Fault
code
Fault
icon
Fault
LEDs Description Solutions
