LITHIUM SERIES® II Electric Torque Tool Operations Manual
6
The LITHIUM SERIES® II Tool is the next generation electric torque tool with major advances resulting in greater
durability, expanded unctionality, and intuitive usability. The new brushless 36V DC motor has more than 5 times longer
lie than its predecessor. The tool incorporates TorcSense™ Technology which directly measures torque providing more
repeatable results. Now standard with Bluetooth wireless technology makes data acquisition and irmware upgrades
easier than ever. The tool is packaged in an all-aluminum housing that signiicantly improves durability or industrial
applications. The user interace has been redesigned rom the ground up to provide intuitive access to all sotware
controlled bolting eatures through the high resolution display and push button control panel. Supplied with the same
36-volt battery system the tool provides sustained power through even the toughest jobs with capacity up to 5000 t-lbs.
This tool provides lexibility to support a variety o conigurations including conventional sockets and reaction arms, the
HYTORC Washer and precision mechanical tensioning with the HYTORC Nut.
Square Drive
Eyelet
Work Light
Battery Release
Pistol Grip
Trigger
Directional Switch
Battery Test Button
and Charge
36V Rechargable and
Interchangeable Battery
Handle Attachment
USB Port
Reaction Spline
Planetary Gearbox
Dual Speed Switch
Brushless DC Motor
Cooling Vents
LCD Screen LED Status
Indicator
Push Buttons
3. TOOL DE SCRIPT ION
