Hyundai Elevator SSVF7 - Page 31

Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 Trouble manual
STVF7 SERIES
TROUBLESHOOTING MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 5 - A4(210㎜×297㎜)
2-2. Total Information Mode
C
1 3 5678 11 1516
V
1 A u C D ↑ ≡ 2(B 1)/3 3
2 F 6 8[0 9 : 2 5]
Position Commit Display
1verse
1,2 column
Elevator Status
No no mode F1 1st fireman op.
Au auto F2 2nd fireman op.
In In-Car inspection Mv independent op.
On On-Car inspection Ep Emergency op.
Mc
Machine room
inspection
El
Emergency
Landing op.
Fi Initialization Eq Earthquake op.
Pk Parking op. Rp Sub brake in
Fr Fireman Return Ar Arrange op.
1verse
3,4 column
Door Status
OG Openning RG Rear Door Openning
OP Open RO Rear Door Open
CG Closing RC Raer Door Close
CD Close
1v 5c Direction ↑: Up, • : Stop, ↓: Down
1v 6c Door zone sensor ULA, DZ, DLA
1v 7c Non-Stop Floor (Space) : Service Floor, * : non-Service Floor
1v 8,9c Absolute Floor
1v 11~12c Floor display Floor display on Indicator
1v 15,16c Total Floor
2v 1,2,3c Error display ---: No error, Fxx: error code
2v 11~15c Current time Hour : Minute
[Table 2. Total Information Mode]
