2-3. IN/OUT MODE
(1) Method of checking IN/OUT status
ex) : 1.1 PIO input status
P I O I N P U T ( 0 ) PIO Input (0) mode
0X00C20017 DATA : 32bit hex value
(a)(b)(a)(b)(a)(b)(a) (b)
④③②①
①-(b) : 7 => 29,41,40 : ON
①-(a) : 1 => AUTO : ON
③-(b) : 2 => FMR : ON
③-(a) : C => MCI,MC2I : ON
* It is same as the other in/out mode.
(2) PIO Input (1. IN/OUT >> 1-1. PIO Input)
HHT
SIGNAL NAME
(a) (b)
8 4 2 1 8 4 2 1
bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1
PIO Input [0]
①MDN MUP MCS
AUTO BKOP 40 41 29
② DLS PLDL PLDH
PLDM PLUM PLUH PLUL ULS
③ MC2I MCI ELDI
EQP EQS PARK FMR RBKI
④ BKB FMR2 RDZ
FDZ EMPO HOME ATS MT
PIO Input [1]
①PDN PUPPHAND
PAUTO RNBL WLS PDLS CTOL
②
③
④
PIO Input [2]
①30B BKS ZSP
RUN DLD DLA DZ ULA
②
[Table 3. PIO Input]
a. If elevator is in machine room inspection, check that "PIO Input[0]" is
whether
---
- --27
or not. (MCS, 40, 41, 29)
b. If limit switches are in good condition, check that "PIO Input[0]" is
whether
---
- E7--
or not. (DLS, PLDL, PLDH, PLUH, PLUL, ULS)
c. If door zone sensors are in good condition, check that "PIO Input[2]" is
whether
---
- ---7
or not. (DLA, DZ, ULA)
d. If inverter is in good condition at stopped, check that "PIO Input[2]" is
whether
---
- --A-
or not. (30B, ZSP)
