Hyundai Elevator SSVF7 - Page 33

Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 Trouble manual
STVF7 SERIES
TROUBLESHOOTING MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 7 - A4(210㎜×297㎜)
(3) PIO Output (1. IN/OUT >> 1-2. PIO Output)
HHT SIGNAL NAME
PIO Output [0]
REV
FWD MC2 MC1 RBK BRKA
XRLY MFAN SPO2
SPO1 ELDO BRKC BRKB ALARM
RST INIT
[Table 4. PIO Output]
a. If elevator is stopped, check that "PIO Output[0]" is
whether
---
- ---6
or not. (MC1, RBK)
* SSVF7 :
---
- ---E
(MC2, MC1, RBK)
b. If elevator is moving upward, check that "PIO Output[0]" is
whether
---
- --17
or not. (FWD, MC1, RBK, BRKA)
* SSVF7 :
---
- --1F
(FWD, MC2, MC1, RBK, BRKA)
(4) Car Input (1. IN/OUT >> 1-3. Car Input)
HHT Signal Name
CarSigIn [0]
FC5 NDZ FC3 FR2 FR1 ONDN ONUP ONS
OL FULL L70 L30 EE SE DCL DOL
DCS DCB DOB INS AUTO
ODD EVEN EACH MOVE PASS ATT PWR
CarSigIn [1]
CarSigIn [2]
REE RSE RDCL RDOL
RDCS RDCB RDOB
CarSigIn [3]
[Table 5. Car Input]
a. If inspection switch on the cage is on, check that "Car Input[0]"
is whether
---
- ---1
or not. (ONS)
b. If door open button is pushed, check that "Car Input[0]" is
whether
--1
- ----
or not. (DOB)
