Hyundai Elevator SSVF7 - Page 40

Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 Trouble manual
STVF7 SERIES
TROUBLESHOOTING MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 14 - A4(210㎜×297㎜)
F42 Initialization Error
State
- After initialization, inverter don't output high operation signal to MCU.
Reference
- Elec.W.diagram : COL 3A, 3B
- MCU HHT : 1.IN/OUT >> 1.1 PIO Input >> PIO Input [0] “ULS, DLS”
- Inverter HHT : MONITOR>>BASIC>>INIT OK
: PROGRAM>>CONTROL>>MAX FLOOR
Check
Point
- Check the door zone sensor input.
- Check the floor data of inverter "MAX FLOOR".
- Check the limit switch position.
F52 Pulse Error
State
- Pulse compensation error (±500mm) in auto operation.
- F42 → move to near door zone
Reference
- Elec.W.diagram : COL 4A
- MCU HHT : 1.IN/OUT >> 1.1 PIO Input >> PIO Input [2] “ULA, DLA”
- Inverter HHT : MONITOR>>FLOOR DATA>>CURRENT POSITION
Check
Point
- Check the door zone sensor input.
- Check the floor data of inverter "MAX FLOOR". ?
- Check the limit switch position.
F62 Vane Count Error
State
- In initialization, the number of door vane is different from total floor data.
- Possible to move in inspection.
Reference
- Elec.W.diagram : COL 3A, 3B, 4A
- MCU HHT : 1.IN/OUT >> 1.1 PIO Input >> PIO Input [0] “ULS, DLS”
- MCU HHT : 1.IN/OUT >> 1.1 PIO Input >> PIO Input [2] “DLA,DZ,ULA”
Check
Point
- Check the door vane and sensor input.
- Check the floor data of inverter "MAX FLOOR".
- Check the limit switch position.
