Hyundai Elevator SSVF7 - Page 41

Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 Trouble manual
STVF7 SERIES
TROUBLESHOOTING MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 15 - A4(210㎜×297㎜)
F13 OPB Line disconnection Error
State
- OPB line disconnection error
- Possible to move in inspection.
Reference
- MCU HHT : 1.IN/OUT>>1.D CAN Status>>CAN.Car Status
Check
Point
- Check the OPB line and OPB board.
- HHT "CAN.Car Status" : 0x000000** (normal)
: 0x800000** (abnormal)
F23 OPB bus off Error
State
- MCU commands to stop communication as noise.
- Possible to move in inspection.
Reference
- MCU HHT : 1.IN/OUT>>1.D CAN Status>>CAN.Car Status
Check
Point
- Check line noise and OPB board.
- Check ground condition of machine room.
F63 OPB Communication Error
State
- OPB line is correct, but communication data error occurs.
- Possible to move in inspection.
Reference
- MCU HHT : 1.IN/OUT>>1.D CAN Status>>CAN.Car Status
Check
Point
- Check communication line and OPB board.
- Check OPB board dip switch. (all dip switches must be off)
F73 OPB Communication Checksum Error
State
- OPB line is correct, but communication data error occurs.
- Possible to move in inspection.
Reference
- MCU HHT : 1.IN/OUT>>1.D CAN Status>>CAN.Car Status
Check
Point
- Check communication line and OPB board.
- Check line noise and ground condition of machine room.
