Hyundai Elevator SSVF7 - Page 42

Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 Trouble manual
STVF7 SERIES
TROUBLESHOOTING MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 16 - A4(210㎜×297㎜)
F14 Door Error(In running)
State
- Interlock switch or gate switch is not on while elevator running.
- F14 → impossible to move in any operation.
Reference
- Elec.W.diagram : COL 3A, 3B, 3C, 4A
- MCU HHT : 1.IN/OUT >> 1.1 PIO Input >> PIO Input [0] “40, 41”
Check
Point
- Check hatch door interlock switch and gate switch.
- Check "CT4", "CT5" connectors status of TNP board.
- Check "X40", "X41" relays status of TNP board.
F24 Door Jumper Error
State
- Interlock or gate switch jumper when car door is open fully.
Reference
- Elec.W.diagram : COL 3A, 3B, 3C, 4A
- MCU HHT : 1.IN/OUT >> 1.1 PIO Input >> PIO Input [0] “40, 41”
- MCU HHT : 1.IN/OUT >> 1.3 Car Input >> CarSigIn [0] “DOL, DCL”
Check
Point
- Check hatch door interlock switch and gate switch.
- Check "CT4", "CT5" connectors status of TNP board.
- Check "X40", "X41" relays status of TNP board.
F34 DCL Error
State
- No "DCL" signal input after trying to close 3 times.
Reference
- Elec.W.diagram : COL 6A, 6B, 6C
- MCU HHT : 1.IN/OUT >> 1.3 Car Input >> CarSigIn [0] “DCL”
Check
Point
- Check "DCL" signal and sensor state.
- Check door sill and obstacles.
- Check "CC13" connector of CCB-7 board.
