Hyundai Elevator SSVF7 - Page 49

Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 Trouble manual
STVF7 SERIES
TROUBLESHOOTING MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 23 - A4(210㎜×297㎜)
F47 Relevel Landing Error
State
- Out of door zone in door open relevel landing operation
Reference
- Elec.W.diagram : COL 4A
- MCU HHT : 1.IN/OUT >> 1.1 PIO Input >> PIO Input [2] "ULA, DLA"
Check
Point
- Check the door zone sensor input "ULA, DZ, DLA" and its connection.
- Check the "T1" harness of TNP board and CCB-7 board.
- Check the gap between door zone sensors. (135mm)
- Check the door zone vane and its length. (300mm)
- Check inverter data "PROGRAM>>CONTROL>>RELEVEL RPM".
F57 ULS/DLS Error (In running)
State
- "ULS" or "DLS" limit switch activated in running.
Reference
- Elec.W.diagram : COL 3A, 3B, 10A, 10B
- MCU HHT : 1.IN/OUT >> 1.1 PIO Input >> PIO Input [0] "ULS, DLS"
Check
Point
- Check the limit switch "ULS, DLS", its connection and position.
- Check "CT1", "CT2" connector of TNP board.
- Check the MCU HHT data "PIO Input[0]>>ULS,DLS".
F67 PLU/PLD Error (Deceleration Fault)
State
- "PLUL" or "PLDL" limit switch activated in auto operation
without deceleration.
Reference
- Elec.W.diagram : COL 3A, 3B, 10A, 10B
- MCU HHT : 1.IN/OUT >> 1.1 PIO Input >> PIO Input [0] "PLUL, PLDL"
Check
Point
- Check the limit switch "PLUL, PLDL" and its position.
- Check "CT1", "CT2" connector of TNP board.
- Check the inverter errors and floor data. (MONITOR>>FLOOR DATA)
- Do Initializating operation again.
