Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 Trouble manual
STVF7 SERIES
TROUBLESHOOTING MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 24 - A4(210㎜×297㎜)
F77 PLUL/PLDL Error (Floor Confirm Error)
State
- No PLUL switch input at top floor in auto operation.
- No PLDL switch input at bottom floor in auto operation.
Reference
- Elec.W.diagram : COL 3A, 3B, 10A, 10B
- MCU HHT : 1.IN/OUT >> 1.1 PIO Input >> PIO Input [0] "PLUL, PLDL"
Check
Point
- Check the limit switch "PLUL, PLDL" and its position.
- Check "CT1", "CT2" connector of TNP board.
- Check the inverter errors and floor data. (MONITOR>>FLOOR DATA)
F18 Group Communication Error
State
① communication error in ring group
② GIO board error in duplex group
- both ①,② are possible to move in auto single operation.
Reference
- Elec.W.diagram : COL 18A, 18B
- MCU HHT :
① 3.SETUP>>3.1 Basic>>31b Field>>B23 Group Mode
② 1.IN/OUT >> 1.C Group Output >>C24 GOFLAG[7]>>"0x81"
Check
Point
- Check MCU HHT data.
- Check the state whether in auto operation or not.
- Check GIO board connection of MCU board.
- Check GIO board LED state. (refer to "STVF7 ADJUSTMENT MANUAL")
F28 RMS Communication Error
State
- RMS(Remote Monitoring System) communication error
- Possible to move in any operation.
Reference
- Elec.W.diagram : COL 7B
- MCU HHT : 3.SETUP>>3.1 Basic>>31b Field>>B22 RMS use>>"Enable"
Check
Point
- Check "H1" connector of MCU board.
- Check the power supply of RMS board.
