Hyundai Elevator SSVF7 - Page 51

Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 Trouble manual
STVF7 SERIES
TROUBLESHOOTING MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 25 - A4(210㎜×297㎜)
F38 RNBL Error
State
- "RNBL(Run-By-Limit)" switch is activated while E/L is running.
- F38 occurs → buzzer on
- Possible to move in any operation
Reference
- Elec.W.diagram : COL 3B
- MCU HHT : 1.IN/OUT >> 1.1 PIO Input >> PIO Input [1] "RNBL"
Check
Point
- Check the "RNBL" switch connection.
- Check the main rope tension.
F58 LS Board Communication Error
State
- LS board communication error in case of "LXVF7, SSVF7"
- Possible to move in any operation
Reference
- Elec.W.diagram : COL 7A
- MCU HHT : 3.SETUP>>3.1 Basic>>31a General>>A20 Load Sensor
Check
Point
- Check the LS board connection.
- Check the CAN communication line between OPB and LS board.
- Check the "JU1" jumper pin of OPB board. (short)
F68 Hall Communication Error
State
- Hall-CAN board communication error
- Possible to move in any operation
Reference
- Elec.W.diagram : COL 8A, 11A, 11B
- MCU HHT : 2.ERROR>>2.3Hall Error>> HallErr.1, HallErr.2
Check
Point
- Check MCU HHT : 2.ERROR>>2.3Hall Error>> HallErr.1, HallErr.2
- Check the communication line.
- Check the Hall-CAN board state and dip switch adjustment.
(refer to "STVF7 ADJUSTMENT MANUAL)
