Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 Trouble manual
STVF7 SERIES
TROUBLESHOOTING MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 26 - A4(210㎜×297㎜)
F78 MC2 Contactor Error (At starting)
State
- No "MC2" contactor input at starting in case of SSVF7
- Impossible to move in any operation
Reference
- Elec.W.diagram : COL 1C, 3C, 4A
- MCU HHT : 1.IN/OUT >> 1.1 PIO Input >> PIO Input [0] "MC2I"
- MCU HHT : 1.IN/OUT >> 1.2 PIO Output >> PIO Output [0] "MC2"
Check
Point
- Check the "MCX2" relay of TNP board.
- Check "MC2" contactor connection.
- Check "CT55" connector of TNP board.
F59 LS Setting Error
State
- No LS setting in case of LXVF7 and SSVF7
- Possible to move in any operation
Reference
- Elec.W.diagram : COL 7A
- MCU HHT : 3.SETUP>>3.1 Basic>>31a General>>A20 Load Sensor
Check
Point
- Do LS board setting according to "STVF7 ADJUSTMENT MANUAL"
① HHT : 20a LS Use → "Enable"
② 20c Sensing Data → 9000~10000 (check LS sensor position)
③ load 0% in cage
④ HHT : 20b Load Setting>>0% "settable"
(check in door zone and inspection switch in Machine room)
⑤ HHT : 0% >> "YES" enter → "waiting"
⑥ 0% setting end (buzzer)
⑦ load 50% in cage
⑧ HHT : 50% >> "settable" → "YES" enter → "waiting"
⑨ 50% setting end (buzzer twice)
