This is the pinout of the target cTI20 JTAG header. Pin 6 should be missing to indicate
the proper orientation.
These are the top view dimensions of the ADA-MIPI20-cTI20 adapter:
These are the side view dimensions of the ADA-MIPI20-cTI20 adapter:
A 0.74 in (18.9 mm)
B 0.7 in (17.7 mm)
C 0.76 in (19.4 mm)
D 0.07 in (1.8 mm)
J 0.24 in (6.0 mm)
K 0.50 in (12.8 mm)
TMS
TDI
TVD (PD)
TDO
TCKRTN
TCK
EMU0
nSYSRST
EMU2 (NC)
EMU4 (NC)
nTRST
TDIS
KEY
GND
GND
GND
EMU1
GND
EMU3 (NC)
GND
12
3
4
56
7
8
910
11
12
13
14
15 16
17
18
19
20
