Technical specifications
IAR Debug Probes User Guide
I-jet®, I-jet Trace, and I-scope™
6 Input TDO
/SWO
SWD trace output port. Optional—not required for
SWD operation.
Yellow Input VTref The target reference voltage. Used by I-jet to check
whether the target has power, to create the logic-level
reference for the input comparators, and to control the
output logic levels to the target. It is normally fed from
the target’s VDD voltage.
Red Output 5V Output This pin can be used for supplying 5V power to the
target hardware from I-jet.
Pin
I-jet
direction
Name Description
Table 12: ADA-MIPI20-STSWD6 adapter pin definitions (Continued)
