INSTALLATIONS
8
IB895 User’s Manual
Jumper Locations on IB895
Jumpers on IB895............................................................................ Page
JP2: Clear CMOS Contents ...................................................................9
JP3: BL Voltage Setting ........................................................................9
JP5: COM1 RS232 RI/+5V/+12V Power Setting.................................. 9
JP6: LVDS Panel Power Selection........................................................9
JP7: BL_ADJ_LEVEL Setting............................................................10
JP8: Factory use only........................................................................... 10
SW1 : LVDS Panel Type setting .........................................................10
