INSTALLATIONS
10 IB895 User’s Manual
JP7: BL_ADJ_LEVEL Setting
JP7 Setting Voltage
Open
3.3V
Close
5V(default)
JP8: Factory use only
SW1: LVDS Panel Type Setting
SW1-4 SW1-3 SW1-2 SW1-1 Panel T
yp
e
ON ON ON ON 800*600 18bit 1ch
ON ON ON OFF 1024*768 18bit 1ch
ON ON OFF ON 1024*768 24bit 1ch
ON ON OFF OFF 1280*768 18bit 1ch
ON OFF ON ON 1280*800 18bit 1ch
ON OFF ON OFF 1280*960 18bit 1ch
ON OFF OFF ON 1280*1024 24bit 2ch
ON OFF OFF OFF 1366*768 18bit 1ch
OFF ON ON ON 1366*768 24bit 1ch
OFF ON ON OFF 1440*900 24bit 2ch
OFF ON OFF ON 1440*1050 24bit 2ch
OFF ON OFF OFF 1600*900 24bit 2ch
OFF OFF ON ON 1680*1050 24bit 2ch
OFF OFF ON OFF 1600*1200 24bit 2ch
OFF OFF OFF ON 1920*1080 24bit 2ch
OFF OFF OFF OFF 1920*1200 24bit 2ch
