INTRODUCTION
IB895 User’s Manual 3
IB895 Specifications
Product Name
IB895 [default silk screen model # on PCB]
IB895N(N2600 onboard)
Form Factor
3.5”
CPU
Type/Speed
Intel® Atom
TM
DC D2550 / 1MB cache / 1.86 GHz [TDP=10W] (IB895)
Intel® Atom
TM
DC N2600 / 1MB cache / 1.60 GHz [TDP=3.5W]
(IB895N)
Package = FCBGA437 [ 22 mm x 22 mm] ; Cores / Threads = 2 / 4
Chipset
Intel
®
CG82NM10 PCH [TDP = 2.1W]
Package = BGA360, 17mm x 17 mm
BIOS
AMI BIOS, support ACPI Function
Memory
Intel
®
Atom
TM
on-die memory controller
1x DDR3-1066 SO-DIMM socket [Horizontal type]
Maximum memory: 4GB for D2550; 2GB for N2600
Non-ECC, Unbuffered, 1.5V
VGA
Intel® GMA 3650 (Gfx freq @ 640MHz) for D2550
Intel® Graphics Media Acc GMA elerator 3600 (Gfx freq @ 400MHz)
for N2600
Supports DirectX 9 Graphics, OpenGL 3.0
DVI-I
x 1 (Thru VGA + ASM1422 for DVI-D via D2550 or N2600)
LVDS
24-bit dual channel via CH7511thru eDP
LAN
Intel 82583V PCIe Gigabit LAN x 2
USB
NM10 built-in USB 2.0 host controller, support 6 ports
Serial ATA
Ports
NM10 built-in SATA II controller, supports 2 ports
Audio
Intel
®
NM10 PCH built-in HD Audio controller + Realtek ALC269QHD
Codec w/class-D speaker amplifier(2.3W per channel @ 5V power
supply) [7mm x 7mm @ 48-QFN] ; support 2-channel audio out + amp
LPC I/O
Nuvoton NCT6627UD [128-pin QFP, 14x14x1.4mm]
- COM #1 (RS232/422/485) support ring-in with power @500 mA
(selectable for 5V or 12V) [EXAR SP339EER1 232/422/485
transceiver x 1 for jumper-less]
- COM #2 (RS232 only)
- COM #3 / COM #4 (RS-232 only)
[Hardware Monitor]
2 x Thermal inputs; 2 x Voltage monitoring
1 x Fan Header(DC Fan type)
Digital IO
4 in & 4 out
Keyboard/
Mouse Connector
Pin headers
Expansion
Slots
Mini PCI-e socket x 2 (1x Full-sized+1xHalf-sized)
**Full-sized MiniPCIe(1x) support mSATA**
Edge
Connector
DVI-I, 2x RJ45, 2x USB, COM1
Onboard
Header/Connector
Keyboard/mouse, 4x USB 2.0, 2x DF13 for 24-bit dual channel LVDS,
Audio, speaker, COM2, COM3/4, LPC (80-port card debugging
purpose), 2x Mini PCI-e(1x), smart battery, backlight/brightness
control, 2x power connector SATA HDD [JST type]
