IBASE Technology IB895 - Serial Port Configuration; Super Io Configuration

BIOS SETUP
IB895 User’s Manual 29
Super IO Configuration
Aptio Setup Utility
Main Advanced Chipset Boot Security Save & Exit
W83627UHG Super IO Configuration
Super IO Chip Winbond W83627UHG
► W83627UHG Serial Port 0 Configuration
► W83627UHG Serial Port 1 Configuration
► W83627UHG Serial Port 2 Configuration
► W83627UHG Serial Port 3 Configuration
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save & EXIT
E
SC: Exit
Serial Port Configuration
Set Parameters of Serial Ports. User can Enable/Disable the serial port
and Select an optimal settings for the Super IO Device.
H/W Monitor
Aptio Setup Utility
Main
Advanced Chipset Boot Security Save & Exit
Pc Health Status
System temperature +50 C
CPU temperature +55 C
CPU Fan Speed N/A
VCORE +1.184 V
+12V +12.032 V
+3.3V +3.248 V
+5V +4.960 V
CPU Shutdown Temperature Disabled
SmartFan Control Disabled
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save & EXIT
E
SC: Exit
Temperatures/Voltages
These fields are the parameters of the hardware monitoring function
feature of the motherboard. The values are read-only values as
monitored by the system and show the PC health status.
