INTRODUCTION
IB895 User’s Manual 1
Introduction
Product Description
The IB895 is a 3.5-inch single board computer based on the Intel
®
Atom
Cedarview chipset. The Cedar Trail is a platform that uses the Intel
Cedarview-D or Cedarview -M Processor and Intel NM10 Express
Chipset family in the desktop platforms.
The role of the processor in the system is to manage the flow of
information between the following interfaces: DDR3 System Memory
interface, DVI display interface, VGA graphics interface, Low Voltage
Differential Signaling (LVDS) and the Direct Media Interface (DMI).
The processor supports single channel, one DDR3 SODIMMs.
The Intel
®
processors provide advanced performance in both computing
and graphics quality. This meets the requirement of customers in the
gaming, POS, digital signage and server market segment.
The processor is built on 32-nanometer Hi-K process technology with
Micro-FCBGA11 packaging.
IB895 FEATURES:
 Supports Intel
®
Cedarview -D and Cedarview-M processors
 One DDR3 SO-DIMM, 800/1066 MHz, Max. 2GB/4GB
memory*
 Integrated Graphics for DVI-I, LVDS displays
 2 x SATA Connector
 4x COM Port Connector
 2 x Mini-PCIe(x1) slot (w/ USB support)
 2x GbE (RJ-45) Connector
 1x 24V to 12V DC-IN Power Connector
* Note: IB895 with Intel Atom D2550 supports up to 4GB memory
and IB895N with Intel Atom N2600 supports up to 2GB memory.
