BIOS SETUP
IB895 User’s Manual 33
South Bridge
This section allows you to configure the South Bridge Chipset.
Aptio Setup Utility
Main Advanced Chipset Boot Security Save & Exit
► TPT Device
► PCI Express Root Port0
► PCI Express Root Port1
► PCI Express Root Port2
► PCI Express Root Port3
DMI Link ASPM Control Enabled
PCI-Exp. High Priority Port Disabled
High Precision Event Timer Configuration
High Precision Timer Enabled
SLP_SP4 Assertion Width 1-2 Seconds
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save & EXIT
SC: Exit
DMI Clink ASPM Control
The control of Active State Power Management on both NB side and SB
side of the DMI Link.
PCI-Exp. High Priority Port
The options are Disabled, Port1, Port2, Port3, and Port4.
High Precision Event Timer Configuration
Enable/or Disable the High Precision Event Timer.
SLP_S4 Assertion Stretch Enable
Select a minimum assertion width of the SLP_S4# signal.
