IB990 User’s Manual
1.5 Specifications
Product
Name
IB990AF
(for Q170)
IB990AF-C236
(for C236)
Form Factor
PICMG 1.3 SHB Express full size CPU card
System
Operating
System
 Windows 10 (64b)
 Windows 8.1 (64b) / Embedded Industrial (64b)
 Windows 7 Pro (32b/64b)
 Linux Fedora (64b) / Ubuntu (64b)
CPU Type
 Intel
®
Xeon
®
E3 processor v5 Family (14nm
monolithic)
 Intel
®
6
th
Gen. Core
TM
i7 / i5 / i3 DT processor
(14nm monolithic)
TDP: QC @ 35W / 65W / 80W ; DC@ 35W / 65W
Package: 37.5 mm x 37.5 mm x 4.4 mm
CPU Speed
Up to 4.0 GHz
CPU Socket
LGA1151
Chipset
Intel
®
PCH-H, Package = FCBGA 23 mm x 23 mm x
0.5 mm
Q170
C236
Security
TPM 1.2
N/A
Memory
Intel
®
6
th
Gen. Core
TM
DT processors integrated
memory controller
 DDR4-2133 MHz at 1.2V
 2 x UDIMM (288-pin vertical type), Max. 32GB
* ECC will be supported by identified CPU SKUs.
iAMT 11.0
Yes
Watchdog
Timer
Yes (256 segments, 0, 1, 2…255 sec / min)
BIOS
AMI BIOS
