General Information
IB990 User’s Manual
5
1
Product
Name
IB990AF
(for Q170)
IB990AF-C236
(for C236)
System
Voltage
+5V, +3.3V, +12V, -12V & 5VSB
Dimensions
338mm x 126mm
RoHS
Yes
Certification
CE, FCC, LVD
I/O Ports
SATA
Intel
®
PCH-H built-in SATA controller, SATAIII (3.0) 6
Gbps
6 ports:
 4 ports on board
 2 ports to backplane
8 ports:
 6 ports on board
 2 ports to backplane
LAN
 Intel
®
I219LM GbE PHY (Supports iAMT)
 Intel
®
I211AT GbE LAN as 2
nd
GbE
* There is no LAN signal to the backplane.
USB
4 x USB 2.0 host controller (PCH-H Integrated)
 2 ports (on-board pin header)
 2 ports (on-board USB connector, vertical type)
3 x USB 3.0 host controller (PCH-H integrated)
 1 port via the rear panel I/O
 2 ports via on board box header
Audio
Intel
®
PCH-H built-in high definition audio with Realtek
ALC662 Codec
Supports 5.1 channel
