6
IB990 User’s Manual
Product
Name
IB990AF
(for Q170)
IB990AF-C236
(for C236)
Super I/O
Fintek F81846AD-I
 COM1 (RS-232 /422 / 485) supports ring-in with
power at 500 mA (selectable for 5V or 12V)
*F81439 transceiver for jumper-less selection
 COM2~ COM4 (RS-232 only)
Hardware Monitor
(2 thermal inputs, 4 voltage monitor inputs & 2 Fan
headers)
 1 x CPU Fan (PWM fan type, 4-pin connector)
 1 x SYS Fan (DC fan type, 3-pin connector)
 1 x Parallel port
Digital IO
4 In & 4 Out
KB / Mouse
Supports PS/2 Keyboard / Mouse
Interface
1 x PCIe (x16)
4 x PCIe (x1) or 1 x PCIe (x4)
4 x PCI masters (through ITE IT8892E)
Expansion
Slots
1 x Mini-PCIe slot
 Supports USB 2.0
 Supports PCIe (x1) signal
Display
VGA
Intel
®
Xeon
®
E3 v5 family or Intel
®
6
th
Gen. Core
TM
i7/i5/i3 DT processors integrated graphics
 1 x DVI-I
 1 x CRT (header on board)
 1 x DVI-D (header on board)
