1.0 Introduction
The IBC air handling unit is designed for ducted heating and cooling. The unit provides up to four mounting
options for flexibility and ease of installation. Return air duct connections can be connected left, right, and
bottom to suit the unit's mounting position. For information on mounting positions and sizing, see Cabinet and
air supply dimensions on page 8.
Note that unit's installed with a right side air opening will require the air filter position to be modified. For
instructions, see Repositioning the air filter brackets on page 20.
1.1 Standard features and benefits
Integrated air handling unit
High efficiency motor with variable speed (ECM) centrifugal fan
Quiet operation
Slide out fan assembly
Optional filter rack positioning
High efficiency fin tube coil
