An internal time delay is preset enabling the W2 blower speed after a preset period of time. A
jumper between W1 and W2 will initialize this speed without the time delay.
Optional
Figure 24 Single-stage heating with fan control, on-demand heat source
31
2.6.2 Connecting line voltage - examples for different scenarios
