Required if boiler does not have an integral pump
Dry contact from air handler to boiler / enables call for heat
W1 = boiler + low fan, W2 = boiler + high fan
Not used
Figure 33 Single-stage cooling with boiler heating (2-stage thermostat)
40
Section: Installation
