Page 66 INSTALLATION AND OPERATION MANUAL
ENGLISH
3.4.- FEED GROUP
a) Gasket: facilitates the adjustment of the fi lter holder in the group.
b) Showerhead: where the water is in contact with the co ee.
c) Drainage device.
d) Solenoid valve: it allows the passage of water to the unit when a button on the button pad
is pressed.
The feed group is a pressed brass block in which there is a brewing chamber. When any button on the button pad
is pressed, the pump is started and the solenoid valve is ENABLED.
3.5.- BOILER
a) Feed group.
b) Injector.
c) Heat exchanger.
This boiler is manufactured in copper and a heat exchanger connected to the power supply unit passes through it.
During a supply cycle, cold water is pumped to the co ee boiler through the injector. In turn, the water inside the
co ee boiler is taken to the feed group. Under rest conditions there is permanent fl ow of water between the feed
group and the co ee boiler, which keeps the equipment at the optimum temperature for co ee preparation.
The temperature of the heating elements within the boilers is limited by thermostats. Should the element
temperature exceed that established by the thermostat, the machine will cut the power supply. In order to connect
the elements once more, push the reset button located on the thermostat.
3.5.1. Electrical resistance
MACHINE
No. OF
BOILERS
GROUPS RESISTANCE
IBERITAL INTENZ
1
1 1800W 110-220V / 2400W 110V
2
3000-3500-3800-5000W 220-240V
2400W 110V
3 5000-6000W 220-240V
2
2 3000W + 1000W 220-240V
3 3000W + 1000W 220-240V
IBERITAL L’ANNA 1
1
1800W 110V - 220-240V
2400W 110V
2
3000-3500-3800-5000W 220-240V
2400W 110V
IBERITAL JUNIOR 1 2
3000-3500W 220-240V
2400W - 110V
IBERITAL IB7 1
1
1800W 110V - 220-240V
1800W 110V
2
3000-3500W 220-240V
2400W - 110V
3 5000-6000W 220-240V
NEW IBERITAL 1
2
3000-3500-3800-5000W 220-240V
2400W 110V
3 5000-6000W 220-240V
IBERITAL EXPRESSION
TWO
2
2 3000W + 1000W 220-240V
3 3000W + 1000W 220-240V
3.5.2. Spring-loaded safety valve
In the case of irregular operation in the control of heating elements, the safety valves guarantee the integrity of
the boiler, releasing excess pressure and keeping it from going over 0.18 MPa.
The safety valves are manufactured under strict quality control standards and following very demanding technical
criteria. Once checked by the manufacturer, they are immediately sealed.
3.5.3. Pressure relief valve (anti-vacuum valve)
This valve, located on the boiler, prevents the depressurization of the boiler interior, keeping liquids from being
sucked in through the steam ejectors.
