IBM AS/400e server 85

IBM AS/400e server

General note: Capacities shown may require prerequisites. Some combinations of features

may not be valid.

Note 10: Processor Group is determined by a combination of the Processor and Interactive Feature. The following table

provides a cross reference.

Processor Interactive Feature Processor Feature Processor Group

#2395

#1521 #23A1 P10

#1522 #23A2 P20

#1523 #23A3 P20

#1524 #23A4 P20

#2396

#1521 #23A9 P20

#1522 #23AA P30

#1523 #23AB P30

#1524 #23AC P30

#1525 #23AD P30

#2397

#1521 #23B1 P20

#1522 #23B2 P30

#1523 #23B3 P30

#1524 #23B4 P30

#1525 #23B5 P30

#1526 #23B6 P30

#2398

#1521 #23B8 P30

#1522 #23B9 P40

#1523 #23BA P40

#1524 #23BB P40

#1525 #23BC P40

#1526 #23BD P40

#1527 #23BE P40
