PCI Card Placement Rules 285
PCI Card Placement Rules
Configuration Validation Form
IOP Capacity Table
Notes:
1. By processor, the #2842 and #2843 may not be installed in the following slots:
• Model 270: C02, C07
• Model 820: C01, C05, C06, C07, C11
• Model 830 and 840: C02, C03, C04, C06, C07, C10, C12, C13, C15
• #5074 PCI Expansion Tower: C02, C04, C06, C07, C10, C12, C13, C15
• #5075 PCI Expansion Tower: C01, C04, C06, C08
2. A maximum of four IOAs are allowed on any IOP.
Line # Item Memory Performance
1IOA#1
2IOA#2
3IOA#3
4IOA#4
5Total
6 IOP Capability
IOP Memory Capacity Performance
Capacity
#2843/#9943 PCI IOP Model 820, 830, 840, #5074, #5075 when
attached to Model 820.
SeeNote1.
211 100
#2842 PCI IOP Model 270 and #5075 when attached to Model 270
Embedded IOP Model 270 (CCINs 284D and 284E)
Embedded IOP Model 820 (CCIN 284C)
Embedded IOP
#5075 PCI Expansion Tower (CCIN 284B)
SeeNote1.
100 100
