Towers 225
Towers
If the #5077 is a manufactured unit, select one line cord for each #5077 Migration Tower II. If
the #5077 is converted from a #9251, a line cord is not required to be selected, as the line
cord from the #9251 may be used. However, a line cord may be selected on a #9251 to #5077
conversion if the line cord type is to be changed. Available line cord options are identified in
the
AS/400e System Builder,
SG24-2155.
#5077 is mutually exclusive with #5033, #5034, and #5035.
SPD Expansion Towers
The Expansion Towers and Unit in the following table can attach to the Model 8xx via #5034
or #5035, and #5077 Migration Towers.
Full details on these racks and towers can be found beginning with “Expansion Towers” on
page 211.
SPD Expansion Tower I/O Features
#2686 Optical Link Processor (266 Mps)
This feature is used for attaching #5044. One #2686 is required per #5044. It requires an
Optical Link Processor position in the #9329 or #9331.
Feature Description Prerequisites
#5043
Primary rack converted to secondary rack
(migrated)
--
#5044 System Unit Expansion Rack (migrated) Optical Link Processor (OLP) Card #2686
#5052 Storage Expansion Unit
#5143 and #5072 pr #5082 and one of
#6502, #6512, #6530, #6532, #6533
#5058 Storage Expansion Unit
#5073 or #5083 and one of #6502, #6512,
#6530, #6532, #6533
#5065 Storage/PCI Expansion Tower
One port on #2688 OLP card in a #5077 or in
#9364 System Unit Expansion
#5072
1063M System Unit Expansion
Tower
One port on #2688 OLP card in a #5077 or in
#9364 System Unit Expansion
#5073
1063M System Unit Expansion
Tower
One port on #2688 OLP card in a #5077 or in
#9364 System Unit Expansion
#5082
1063M System Unit Expansion
Tower
One of #6502, #6512, #6530, #6532, #6533
and One port on #2688 OLP card in #9364
System Unit Expansion
#5083 1063M System Unit Expansion See #5082
