IBM AS/400e

AS/400e server 830 167
AS/400e server 830
A feature cross-reference table provided on the AS/400 system can be used to relate the
Processor Feature Code to the Processor and Interactive features visible in the AS/400
configurator. The Processor Feature Code is found by displaying the QPRCFEAT system
value or in the rack configuration. The Processor Feature Code is used when ordering
software license keys. Or refer to the Model 830 Processor/Interactive Feature table on
page 164.
Processor Group is determined by a combination of the Processor and Interactive Feature.
The following table provides a cross reference.
Main Storage
All main storage on the Model 830 is feature main storage. All main storage DIMMS on the
Model 830 must be added in sets of eight (octals) of the same capacity and technology.
There are a total of 64 DIMM slots available on the Model 830. Of the 64 lists, 32 are “base”,
and an additional 32 are available with feature #2881 Main Storage Expansion installed.
The following memory features are available on the Model 830:
• #3000: Migrated 128 MB Main Storage DIMM—
Support only
– Available only on upgrades from Models 620/S20/720 to the Model 830
– Only a quantity of two is supported
– Supported in octal(s) with #3062
Processor Interactive Feature Processor Feature Processor Group
#2400
#1531 #23C1 P20
#1532 #23C2 P30
#1533 #23C3 P30
#1534 #23C4 P30
#1535 #23C5 P30
#2402
#1531 #23D1 P30
#1532 #23D2 P40
#1533 #23D3 P40
#1534 #23D4 P40
#1535 #23D5 P40
#1536 #23D6 P40
#2403
#1531 #23D8 P40
#1532 #23D9 P50
#1533 #23DA P50
#1534 #23DB P50
#1535 #23DC P50
#1536 #23DD P50
#1537 #23DE P50
