AS/400e server 830
164 AS/400e System Handbook
– Provides support for base Console/Workstation IOA
The configurator will determine which feature combinations will be on the order based
on the System Console specify—#5540 or #5544.
The following required features must be ordered:
• Processor (one must be specified)
– #2400 2-way processor (IStar)(1850 CPW)
– #2402 4-way processor (IStar)(4200 CPW)
– #2403 8-way processor (IStar)(7350 CPW)
• Interactive Card (one must be specified; see the following table)
• Main Storage
– #2881 Main Storage Expansion
• Required for #2403 processor
• Required for #2400 and #2402 processors if more than 32 main storage features
are installed
• May be selected if less than 32 main storage features
– A minimum of one set of eight of the same features must be selected
• #3062 - 128 MB Main Storage
• #3064 - 256 MB Main Storage
• #3065 - 512 MB Main Storage
• Integrated Disk Units
Device Parity Protection - All (0041) is the default for disk data protection. With RAID
protection as the default, a minimum of four of the following disk units of equal capacity
must be ordered. If RAID protection is removed from the system order, at least one of the
following disks must be ordered:
– #4314 - 8.58 GB Disk Unit
– #4317 - 8.58 GB 10k RPM Disk Unit
– #4318 - 17.54 GB 10k RPM Disk Unit
– #4324 - 17.54 GB Disk Unit
Processor Feature #2400 #2402 #2403
Interactive CPW
#1531
#1532
#1533
#1534
#1535
#1536
#1537
70
120
240
560
1050
-
-
70
120
240
560
1050
2000
-
70
120
240
560
1050
2000
4550
