Introduction 7
Introduction
Communications (WAN) Functions No Longer Supported
The following functions are no longer supported on current AS/400 product line WAN
hardware (such as the #2609 EIA 232/V.24 Two Line Adapter, the #2610 X.21 Two Line
Adapter and other, older adapters). They are not supported on the #2720 PCI WAN/Twinaxial
IOA, the #2721 or #2745 PCI Two-Line WAN IOA, the #2699 Two-Line WAN IOA, or the
#9771 Base PCI 2-Line WAN with Modem.
• X.21 switched interface (X.21 leased support)
• X.21 Shorthold mode
• V.25 2 port autocall. This is the protocol used to auto dial on switched connections
using modems that require a second port dedicated to the dial function. Do not
confuse this with V.25bis, which is the current day autocall protocol that sends dial
commands over the same port used for data. V.25 bis itself is supported.
• Asynchronous communication speeds of less than 300 bps.
• Data Rate Select signal on the EIA 232/V.24 interface. This function is used by some,
older 2400 bps modems to reduce the speed to 1200 bps.
2482 PTC 05/24/1999
2483 Integrated Laser PTC 05/24/1999
2484 Industrial PTC 05/24/1999
2486 Integrated Laser PTC 05/24/1999
5308 ASCII to 5250 Connection 12/21/1999
5494 Remote Control Unit 12/21/1999
5500 Express IP Control Unit 12/21/1999
6299 Midrange Hub 09/01/1999
7133 IBM 7133 SSA Disk Subsystem Model 010 05/05/1997
7133 IBM 7133 SSA Disk Subsystem Model 020 06/16/1999
8361 -100 Network Station series 100 Ethernet 10/14/1999
8361 - 200 Network Station series 100 Token-Ring 10/14/1999
8361 - 210 Network Station series 300 Token-Ring 12/31/1999
8361 - 341 Network Station series 300 Twinax 12/31/1999
Product or
Feature
Description
Withdrawal Date
