AS/400e server 270
118 AS/400e System Handbook
– Support for base #9767 Base PCI Disk Unit Controller
– Support for up to six Disk Units, the required CD-ROM, and either a feature Internal
Tape or a feature CD-ROM.
Provides support for base Console/Workstation IOA.
The configurator determines which feature combinations will be on the order based on the
System Console #5540 or #5544 specify code.
• Hot plug PCI capability on #2252 and #2253 processors.
The following must be purchased:
• Processor (one must be specified; processor performance CPW is listed)
– #2248 processor (150 CPW)
– #2250 processor (370 CPW)
– #2252 processor (950 CPW)
– #2253 2-way processor (2000 CPW)
• Interactive Card (one must be specified; see the following processor/interactive
feature table for the 270 server)
• Main Storage (a minimum of two of the same capacity and technology must be
selected)
– #3022 - 128 MB Main Storage
– #3024 - 256 MB Main Storage
– #3025 - 512 MB Main Storage
– #3026 - 512 MB Main Storage
• Integrated Disk Units
– #4314 - 8.58 GB Disk Unit
– #4317 - 8.58 GB 10k RPM Disk Unit
– #4318 - 17.54 GB 10k RPM Disk Unit
– #4324 - 17.54 GB Disk Unit
• Integrated CD-ROM
#4525—CD-ROM
Processor Feature #2248 #2250 #2252 #2253
Interactive Feature
#1516 - 0 0 0
#1517 25 - - -
#1518 - 30 - -
#1519 - - 50 -
#1520 - - - 70
Note: The interactive value of zero supports system administrative functions.
