I/O Processor
244 AS/400e System Handbook
The #2790 can support PCI #2744 100 Mbps Token Ring IOAs or #4838 100/10 Mbps
Ethernet IOAs in any combination, up to a maximum of three. At least one LAN IOA is
required. Refer to “PCI Card Placement Rules” on page 279 for details and limitations.
The supported LAN IOA features are as follows:
• #4838 PCI 100/10 Mbps Ethernet IOA
• #2744 PCI 100 Mbps Token Ring IOA
One #0224 (100/10 Mbps Ethernet on Integrated Netfinity Server) is required for each #4838
selected to run on the #2790.
One #0223 (100 Mbps Token-Ring on Integrated Netfinity Server) is required for each #2744
selected to run on the #2790.
Native AS/400 functions are not supported and the #2790 Integrated Netfinity Server does
not support external host LAN.
The #2790 requires three PCI card slots on the system or expansion tower backplane. Two
slots are consumed by the #2790. The third slot is reduced to a short card slot, which will be
used by the first LAN IOA card.
The #2790 will ship with a keyboard/mouse splitter cable.
The #2790 supports only the Window NT and Windows 2000 operating systems and the
following points apply:
• #0325 IPCS Extension Cable for Windows is the default (but may be removed).
• A minimum of 128 MB Netfinity IOP Memory is required.
• #1700 (IPCS Keyboard/Mouse for Windows) is the default (in those countries offering
it).
• A display must be connected to the Integrated Netfinity Server to support Windows.
• For non-US keyboard/mouse and display, see
http://www.as400.ibm.com/nt
Allowable Main Storage Increments (MB)
128 256 384 512 640 768 896 1024
1152 1280 1408 1536 1664 1792 2048
2176 2304 2432 2560 3072
3200 3328 4096
