v Follow the suggested actions in the order in which they are listed in the Action column until the problem is
solved.
v See Chapter 4, “Parts listing, Types 7871 and 1949,” on page 41 to determine which components are CRUs and
which components are FRUs.
v If an action step is preceded by “(Trained service technician only),” that step must be performed only by a
trained service technician.
Error Code Type Error Message Action
0x80010200 Error Expansion Module 1 (BPE3 12V
Sense) voltage under critical
threshold. Reading: X,
Threshold: Y
1. If the under voltage problem is occurring on all
blade servers, look for other events in the IMM
event log related to power and resolve those
events (see “Error logs” on page 99).
2. View the event log provided by the advanced
management module for your BladeCenter unit
and resolve any power related errors that might
be displayed.
3. If other modules or blades are logging the same
issue then check the system power supply,
otherwise replace the Blade PCI Express I/O
expansion unit. See “Removing an optional
expansion unit” on page 57 and “Installing an
optional expansion unit” on page 58.
0x80010200 Error Expansion Module 1 (BPE3
12VSB Sense) voltage under
critical threshold. Reading: X,
Threshold: Y
1. If the under voltage problem is occurring on all
blade servers, look for other events in the log
related to power and resolve those events (see
“Error logs” on page 99).
2. View the event log provided by the advanced
management module for your BladeCenter unit
and resolve any power related errors that might
be displayed.
3. If other modules or blades are logging the same
issue; then, check the power supply for the
BladeCenter unit.
4. If the base blade is not logging a power issue;
then, replace the Blade PCI Express I/O
expansion unit. See “Removing an optional
expansion unit” on page 57 and “Installing an
optional expansion unit” on page 58.
0x80010200 Error Expansion Module 1 (BPE3 3.3V
Sense) voltage under critical
threshold. Reading: X,
Threshold: Y
1. If the under voltage problem is occurring on all
blade servers, look for other events in the log
related to power and resolve those events (see
“Error logs” on page 99).
2. View the event log provided by the advanced
management module for your BladeCenter unit
and resolve any power related errors that might
be displayed.
3. If the base blade is not logging a power issue;
then, replace the Blade PCI Express I/O
expansion unit. See “Removing an optional
expansion unit” on page 57 and “Installing an
optional expansion unit” on page 58.
102 BladeCenter HS22V Type 7871 and 1949: Problem Determination and Service Guide
