Release
handle
Release
buttons
Release
handle
The model number and serial number are on the ID label on the side of the control
panel on the front of the blade server, and on a label on the side of the blade
server that is visible when the blade server is not in the BladeCenter unit.
Important: Do not place the label on the blade server itself or in any way block
the ventilation holes on the blade server.
Serial number
label
A set of blank labels for your blade server comes with the BladeCenter unit. When
you install the blade server in the BladeCenter unit, write identifying information
on a label and place the label on the BladeCenter unit bezel. See the
documentation for your BladeCenter unit for recommended label placement.
2 BladeCenter HS23 Types 7875 and 1929: Installation and User's Guide
