Blade server connectors
Use this information to locate blade server system-board components and
connectors for optional devices.
The following illustration shows the system-board components, including
connectors for user-installable optional devices, in the blade server.
DIMM7
DIMM8
DIMM9
DIMM10
DIMM11
DIMM12
Control panel
connector
SAS 0 hot-swap
storage connector
DIMM 2
DIMM 1
Microprocessor 1
DIMM3
DIMM4
DIMM5
DIMM6
USB connector
CIOv
expansion
connector
Interposer card
connector
Blade
expansion
connector
DIMM13DIMM14
DIMM15
DIMM16
Microprocessor 2
Battery
SAS 1 hot-swap
storage connector
Chapter 2. Power, controls, and indicators 15
