816f000d-0403ffff The Drive [StorageVolumeElementName] has been removed from unit
[PhysicalPackageElementName].
Explanation: Presence of drive 3 is no longer detected. If hard drive is absent from drive bay a filler is required.
May also be shown as 816f000d0403ffff or 0x816f000d0403ffff
Severity: Error
Alert Category: Critical - Hard Disk drive
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0163
SNMP Trap ID: 5
Automatically notify Support: No
User response:
v If drive was intentionally removed, no action required.
v Make sure that the drive properly seated.
v If drive is properly seated, replace the drive.
816f000d-0404ffff The Drive [StorageVolumeElementName] has been removed from unit
[PhysicalPackageElementName].
Explanation: Presence of drive 4 is no longer detected. If hard drive is absent from drive bay a filler is required.
May also be shown as 816f000d0404ffff or 0x816f000d0404ffff
Severity: Error
Alert Category: Critical - Hard Disk drive
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0163
SNMP Trap ID: 5
Automatically notify Support: No
User response:
v If drive was intentionally removed, no action required.
v Make sure that the drive properly seated.
v If drive is properly seated, replace the drive.
816f000d-0405ffff The Drive [StorageVolumeElementName] has been removed from unit
[PhysicalPackageElementName].
Explanation: Presence of drive 5 is no longer detected. If hard drive is absent from drive bay a filler is required.
May also be shown as 816f000d0405ffff or 0x816f000d0405ffff
Severity: Error
Alert Category: Critical - Hard Disk drive
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0163
SNMP Trap ID: 5
Automatically notify Support: No
User response:
v If drive was intentionally removed, no action required.
v Make sure that the drive properly seated.
816f000d-0403ffff • 816f000d-0405ffff
Chapter 6. Troubleshooting 309
