Table 12. DIMM population sequence for independent-channel mode (continued)
Number of DIMMs
installed
1 microprocessor
installed
2 microprocessors
installed
4 microprocessors
installed
21 DIMMs 1, 2, 3, 4, 5,
6, 7, 8, 9, 11, 12, 13,
15, 14, 16, 17, 18, 20,
21, 23, and 24
DIMMs 1, 2, 4, 5, 9,
12, 13, 16, 17, 21, 24,
25, 28, 32, 33, 36, 37,
40, 44, 45, and 48
22 DIMMs 1, 2, 3, 4, 5,
6, 7, 8, 9, 11, 12, 13,
15, 14, 16, 17, 18, 19,
20, 21, 23, and 24
DIMMs 1, 2, 4, 5, 9,
12, 13, 14, 16, 17, 21,
24, 25, 28, 32, 33, 36,
37, 40, 44, 45, and 48
23 DIMMs 1, 2, 3, 4, 5,
6, 7, 8, 9, 10, 11, 12,
13, 15, 14, 16, 17, 18,
19, 20, 21, 23, and 24
DIMMs 1, 2, 4, 5, 9,
12, 13, 14, 16, 17, 21,
24, 25, 28, 32, 33, 35,
36, 37, 40, 44, 45, and
48
24 DIMMs 1, 2, 3, 4, 5,
6, 7, 8, 9, 10, 11, 12,
13, 15, 14, 16, 17, 18,
19, 20, 21, 22, 23, and
24
DIMMs 1, 2, 4, 5, 9,
12, 13, 14, 16, 17, 21,
24, 25, 28, 32, 33, 35,
36, 37, 40, 44, 45, 47,
and 48
25 DIMMs 1, 2, 4, 5, 8,
9, 12, 13, 14, 16, 17,
21, 24, 25, 28, 32, 33,
35, 36, 37, 40, 44, 45,
47, and 48
26 DIMMs 1, 2, 4, 5, 8,
9, 12, 13, 14, 16, 17,
20, 21, 24, 25, 28, 32,
33, 35, 36, 37, 40, 44,
45, 47, and 48
27 DIMMs 1, 2, 4, 5, 8,
9, 12, 13, 14, 16, 17,
20, 21, 24, 25, 28, 29,
32, 33, 35, 36, 37, 40,
44, 45, 47, and 48
28 DIMMs 1, 2, 4, 5, 8,
9, 12, 13, 14, 16, 17,
20, 21, 24, 25, 28, 29,
32, 33, 35, 36, 37, 40,
41, 44, 45, 47, and 48
29 DIMMs 1, 2, 4, 5, 8,
9, 11, 12, 13, 14, 16,
17, 20, 21, 24, 25, 28,
29, 32, 33, 35, 36, 37,
40, 41, 44, 45, 47, and
48
30 DIMMs 1, 2, 4, 5, 8,
9, 11, 12, 13, 14, 16,
17, 20, 21, 23, 24, 25,
28, 29, 32, 33, 35, 36,
37, 40, 41, 44, 45, 47,
and 48
