IBM Flex System x440 Compute Node User Manual

Table 12. DIMM population sequence for independent-channel mode (continued)
Number of DIMMs
installed
1 microprocessor
installed
2 microprocessors
installed
4 microprocessors
installed
46 DIMMs 1, 2, 3, 4, 5,
6, 7, 8, 9, 10, 11, 12,
13, 14, 15, 16, 17, 18,
19, 20, 21, 22, 23, 24,
25, 26, 28, 29, 30, 31,
32, 33, 34, 35, 36, 37,
38, 40, 41, 42, 43, 44,
45, 46, 47, and 48
47 DIMMs 1, 2, 3, 4, 5,
6, 7, 8, 9, 10, 11, 12,
13, 14, 15, 16, 17, 18,
19, 20, 21, 22, 23, 24,
25, 26, 27, 28, 29, 30,
31, 32, 33, 34, 35, 36,
37, 38, 40, 41, 42, 43,
44, 45, 46, 47, and 48
48 DIMMs 1, 2, 3, 4, 5,
6, 7, 8, 9, 10, 11, 12,
13, 14, 15, 16, 17, 18,
19, 20, 21, 22, 23, 24,
25, 26, 27, 28, 29, 30,
31, 32, 33, 34, 35, 36,
37, 38, 39, 40, 41, 42,
43, 44, 45, 46, 47, and
48
Install DIMMs in the order that is indicated in the following table for
mirrored-channel mode.
Table 13. DIMM population sequence for mirrored-channel mode
Number of DIMM
pairs installed
1 microprocessor
installed
2 microprocessor
installed
4 microprocessor
installed
1 DIMMs 1 and 4
1
DIMMs 1 and 4
1
DIMMs 1 and 4
1
2 DIMMs 1 and 4, 9
and 12
1
DIMMs 1 and 4, 13
and 16
1
DIMMs 1 and 4, 13
and 16
1
3 DIMMs 1 and 4, 9
and 12, 2 and 5
1
DIMMs 1 and 4, 13
and 16, 9 and 12
1
DIMMs 1 and 4, 13
and 16, 33 and 36
1
4 DIMMs 1 and 4, 9
and 12, 2 and 5, 8
and 11
1
DIMMs 1 and 4, 13
and 16, 9 and 12, 21
and 24
1
DIMMs 1 and 4, 13
and 16, 33 and 36, 45
and 48
1
5 DIMMs 1 and 4, 9
and 12, 2 and 5, 8
and 11, 3 and 6
1
DIMMs 1 and 4, 13
and 16, 9 and 12, 21
and 24, 2 and 5
1
DIMMs 1 and 4, 13
and 16, 33 and 36, 45
and 48, 9 and 12
1
6 DIMMs 1 and 4, 9
and 12, 2 and 5, 8
and 11, 3 and 6, 7
and 10
1
DIMMs 1 and 4, 13
and 16, 9 and 12, 21
and 24, 2 and 5, and
14 and 17
1
DIMMs 1 and 4, 13
and 16, 33 and 36, 45
and 48, 9 and 12, 21
and 24
1
7 DIMMs 1 and 4, 13
and 16, 9 and 12, 21
and 24, 2 and 5, and
14 and 17, 8 and 11
1
DIMMs 1 and 4, 13
and 16, 33 and 36, 45
and 48, 9 and 12, 21
and 24, 25 and 28
1
Chapter 7. Installing, removing, and replacing compute node components 513
