v Tier 1 customer replaceable unit (CRU): Replacement of Tier 1 CRUs is your
responsibility. If IBM installs a Tier 1 CRU at your request without a service
contract, you will be charged for the installation.
v Tier 2 customer replaceable unit: You may install a Tier 2 CRU yourself or
request IBM to install it, at no additional charge, under the type of warranty
service that is designated for your compute node. Tier 2 CRUs should be
installed only by trained service technicians.
For information about the terms of the warranty and getting service and assistance,
see the Warranty Information document.
Index Description
CRU part
number (Tier
1)
CRU part
number (Tier
2)
1 Top cover (see "Consumable parts")
2 Center Air baffle 00D6314
3 Air baffle above DIMMs (see "Consumable parts")
4 IBM Flex System FC3172 2-port 8 Gb FC Adapter 69Y1941
4 IBM Flex System F5022 2-port 16 Gb FC Adapter 88Y6373
4 IBM Flex System IB6132 2-port FDR Infiniband Adapter 90Y3457
4 IBM Flex System EN4132 2-port 10 Gb Ethernet Adapter 90Y3469
4 IBM Flex System EN2024 4-port 1 Gb Ethernet Adapter 49Y7902
4 IBM Flex System CN4054 10 Gb Virtual Fabric Adapter 90Y3557
4 IBM Flex System FC3052 2-Port 8 Gb FC Adapter 95Y2378
4 IBM ServeRAID-M5115 SAS/SATA RAID Controller 00D5073
5
Memory, 8 GB 2Rx42Gbit DDR-3 1600 MHz 1.5V LP RDIMM (Type
2584, models C2x, C4x) (Type 7917, models F2x, F4x)
90Y3111
5 Memory, 4 GB 1Rx42Gbit DDR-3 1333 MHz 1.35V LP RDIMM 49Y1424
5 Memory, 4GB 2Rx82Gbit DDR-3 1333 MHz 1.35V LP RDIMM 49Y1425
5
Memory, 8 GB 2R x4 2 Gbit DDR-3 1333 MHz 1.35V LP RDIMM (Type
7917, models A2x, A4x, B2x, B4x, C2x, C4x, D2x, D4x)
49Y1415
5 Memory, 16 GB 2Rx44Gbit DDR-3 1333 MHz 1.35V LP RDIMM 49Y1565
5 Memory, 16 GB 4Rx42Gbit DDR-3 1333 MHz 1.35V LP LR-DIMM ) 49Y1569
5 Memory, 4 GB 1Rx42Gbit DDR-3 1600MHz 1.5V LP RDIMM 49Y1561
5 Memory, 16 GB 2Rx44Gbit DDR-3 1600MHz 1.5V LP RDIMM 00D4970
5 Memory, 32 GB 4Rx44Gbit DDR-3 1333MHz 1.35V LP LR-DIMM 90Y3107
6
Intel Xeon Processor E5-4603, 4C 2.0 GHz 10 MB Cache 1066 MHz 95W
(Type 7917, models A2x, A4x)
88Y6264
6
Intel Xeon Processor E5-4607, 6C 2.2 GHz 12 MB Cache 1066 MHz 95W
(Type 7917, models B2x, B4x)
69Y3101
6
Intel Xeon Processor E5-4620, 8C 2.2 GHz 16 MB Cache 1333 MHz 95W
(Type 7917, models D2x, D4x)
69Y3113
6
Intel Xeon Processor E5-4610, 6C 2.4 GHz 15 MB Cache 1333 MHz 95W
(Type 2584, models C2x, C4x) (Type 7917, models C2x, C4x)
69Y3107
6 Intel Xeon Processor E5-4640, 8C 2.4 GHz 20 MB Cache 1600 MHz 95W 90Y9056
6
Intel Xeon Processor E5-4650, 8C 2.7 GHz 20 MB Cache 1600 MHz 130W
(Type 7917, models F2x, F4x)
69Y3119
52 IBM Flex System x440 Compute Node Types 7917 and 2584: Installation and Service Guide
