IBM Flex System x440 Compute Node User Manual

Index Description
CRU part
number (Tier
1)
CRU part
number (Tier
2)
Microprocessor installation tool 94Y9955
Miscellaneous parts kit 46M2832
RFID label tag assembly - EMEA 00E6323
RFID label tag assembly - US 74Y8800
ServeRAID-M5100 series hard disk drive backplane 44E4763
ServeRAID-M5100 series Flex cable assembly 00D5089
ServeRAID-M5100 series solid state drive Flex expansion cable 00D5078
ServeRAID-M5100 Series super capacitor 81Y4579
ServeRAID-M5100 Series super capacitor power cable 44E4767
Thermal grease kit 41Y9292
Consumable parts
Consumable parts are not covered by the IBM Statement of Limited Warranty. The
following consumable parts are available for purchase from the retail store.
Table 4. Consumable parts
Index Description
Consumable part
number
1 Top cover (when ordering this part, order the Label kit
(part number (00D6313)
46M2830
3 Air baffle above DIMMs (Type 2584, models C2x, C4x)
(Type 7917, models A2x, A4x, B2x, B4x, C2x, C4x, D2x,
D4x, F2x, F4x)
81Y5177
7 Filler, 2.5 inch hard disk drive bay (Type 2584, models C2x,
C4x) (Type 7917, models A2x, A4x, B2x, B4x, C2x, C4x,
D2x, D4x, F2x, F4x)
44T2248
10 Filler, microprocessor socket (Type 2584, models C2x, C4x)
(Type 7917, models : A2x, A4x, B2x, B4x, C2x, C4x, D2x,
D4x, F2x, F4x)
00D6325
CMOS battery, 3.0 volt (all models) 33F8354
CRM handle kit 46M2828
Hard disk drive cage, SAS 46M2829
Rear bulkhead assembly full wide 46M2833
ServeRAID-M5115 left-side air baffle 00D5080
ServeRAID-M5115 center air baffle 46C9933
To order a consumable part, complete the following steps:
1. Go to http://www.ibm.com.
2. From the Products menu, select Upgrades, accessories & parts.
3. Click Obtain maintenance parts; then, follow the instructions to order the part
from the retail store.
54 IBM Flex System x440 Compute Node Types 7917 and 2584: Installation and Service Guide
