IBM NetVista - Type 8305;8306;8309;8313 Specifications

36 NetVista™ Technical Information Manual
16 MD12 I/O 72 MD27 I/O 128 CKE0 N/A
17 MD13 I/O 73 VDD N/A 129 S3# I
18 VDD N/A 74 MD28 I/O 130 DQMB6# I
19 MD14 I/O 75 MD29 I/O 131 DQMB7# I
20 MD15 I/O 76 MD30 I/O 132 A15 I
21 NC I/O 77 MD31 I/O 133 VDD N/A
22 NC I/O 78 Ground N/A 134 NC N/A
23 Ground I/O 79 CK2 O 135 NC N/A
24 NC N/A 80 NC N/A 136 NC N/A
25 NC N/A 81 NC O 137 NC I/O
26 VDD N/A 82 SDA O 138 Ground N/A
27 WE# I 83 SCL O 139 MD48 I/O
28 DQMB0# I 84 VDD N/A 140 MD49 I/O
29 DQMB1# I 85 Ground N/A 141 MD50 I/O
30 S0# I 86 MD32 I/O 142 MD51 I/O
31 OE0# I 87 MD33 I/O 143 VDD N/A
32 Ground N/A 88 MD34 I/O 144 MD52 I/O
33 A0 I 89 MD35 I/O 145 NC N/A
34 A2 I 90 VDD N/A 146 VREF N/A
35 A4 I 91 MD36 N/A 147 NC N/A
36 A6 I 92 MD37 I/O 148 Ground N/A
37 A8 I 93 MD38 I/O 149 MD53 I/O
38 A10/AP I 94 MD39 I/O 150 MD54 I/O
39 NC BA1 95 MD40 I/O 151 MD55 I/O
40 VDD N/A 96 Ground N/A 152 Ground N/A
41 NC N/A 97 MD41 I/O 153 MD56 I/O
42 CK0 N/A 98 MD42 I/O 154 MD57 I/O
43 Ground N/A 99 MD43 I/O 155 MD58 I/O
44 OE2# I 100 MD44 I/O 156 MD59 I/O
45 S2# I 101 MD45 I/O 157 VDD N/A
46 DQMB2# I 102 VDD N/A 158 MD60 I/O
47 DQMB3# I 103 MD46 I/O 159 MD61 I/O
48 WE2# I 104 MD47 I/O 160 MD62 I/O
49 VDD N/A 105 NC I/O 161 MD63 I/O
50 NC N/A 106 NC I/O 162 Ground N/A
51 NC N/A 107 Ground N/A 163 CK3 O
52 NC I/O 108 NC N/A 164 NC N/A
53 NC I/O 109 NC N/A 165 SA0 O
Table 21. System memory connector pin input/output
Pin Signal name I/O Pin Signal name I/O Pin Signal name I/O
